TMT GLOBAL cat5e u-utp outdoor 24awg 4pair cable 305Meter TMT GLOBAL Cat6a Elevator Travelling Network Cable are Manufactured Tested and Complied with ANSI/TIA/568.2-D CENELEC EN 50288-5IEC 61156-5 (ISO/IEC-11801 Class -Ea). Cat6a Series is Designed to Ensure the Highest levels of performance, reliability, and longevity, and are ideal for large enterprise and small business.CAT5E U-UTP OUTDOOR 24AWG 4PAIR CABLE 305Meter CAT5E U-UTP OUTDOOR CABLE is a high-quality networking cable manufactured by tmt global technology ltd. This cable is specifically network lan cable cat5e ethernet cable cat5e utp lan cable utp outdoor 22awg 24awg ethernet designed outdoor 22awg 24awg ethernet lan for outdoor use, making it suitable for a wide range of applications in various weather conditions. With a 24AWG gauge and 4 pairs of twisted copper conductors, this cable ensures reliable and fast data transmission. It is compliant with the CAT5E standard, guaranteeing excellent performance and compatibility with various network devices. The 305-meter length provides flexibility in installations, allowing for efficient and convenient networking setups. Choose CAT5E for your outdoor networking needs, and experience reliable connectivity and durability. PHYSICAL AND MECHANICAL PROPERTIES Basic Conductor: 23AWG TMT Copper Insulation: HDPE Number of insulated conductors: 8 twisted in 4 pairs Color Code of Pairs: Blue x White/Blue, Orange x White/Orange, Green x White/Green, Brown x White/Brown Outer Jacket: LSZH Standard Jacket Color: Black /Grey/Blue/Orange/ Green/White/Aqua/ Yellows/Violet/Red Standard Surface Marking: Includes TMT Global P/N, cable description, Meter mark and Model Number Pulling force: 100 N MAX Short Term Bend Radius: 6xOD (Mm) Storage Temperature: -20 To 80C Temperature operating range: -20 to 60C Installation temperature range: 0 to 50C Flame Test: IEC 60332-1 ELECTRICAL SPECIFICATIONS Characteristic Impedance: 100―6 Ohm @ 1-100 MHz DC Resistance: 93 Ohm/Km max. Resistance unbalance: 2% max. Mutual Capacitance: 5.6 nF/100m Max. @ 1 KHz Cap Unbalance (wire to ground): 1500 pF/Km max. @ 1 KHz. Voltage rating: 72 Vdc max. Dielectric strength: 1500 Volts/1 minute min rms Velocity of Propagation (NVP): 67-69% Insulation Resistance: 5000 MOhm•m min. @ 500 Vdc Coupling attenuation: IEC 61156-5 TYPE III
