TMT GLOBAL Optical Connector adapter SC-UPC SM simplex fiber optic adapter TMT GLOBAL Explore the importance of optical connector adapters in fiber optic communication systems. Learn about the features of the LC-APC single mode duplex adapter, including low insertion loss, high return loss, and its bidirectionally capabilities. Discover its applications in telecommunications, data centers, and local area networks, and how it maintains reliable connections in high-density environments.adaptor sm sc upc simplex Optical fiber Improve your understanding of networking equipment and enhance data transmission efficiency with the right optical connectors. adaptor sm scupc simplex Optical fiber simplex fiber optic adapter apc upc sm simplex subscriber sc apc upc sm simplex simplex subscriber optical fiber adapter Features TIA/EIA-604 FOCIS-10 compatible; exceeds TIA/EIA-568-B.3 requirements Complies with IEC 61754-4, Flammability UL94 V-0 standard Available in Flanged and Flangeless options Precision connection with sleeve Low insertion loss, High Return loss Good interchangeability and reliability Meet IEC and ROHS standards High precision of mechanical dimensions Accuracy Products Specifications Adapter Type: LC-LC,SC-SC Polish Type: UPC Body Type: Simplex, Duplex Fiber Mode: Multi Mode Insertion Loss: ≤0.2dB Durability: 1000 time Flammability Rate: UL94-V0 Alignment Sleeve Material: Ceramic Storage Temp（℃）: -40～ 85 General Specification Adapter Type : SC-SC Polish Type : UPC Body Type : Simplex Fiber Mode : Single Mode Insertion Loss : ≤0.2dB Durability : 1000 time Flammability Rate : UL94-V0 Alignment Sleeve Material : Ceramic Storage Temp（℃ : -40～ 85 Products ID : TMT-SCDXU4P Optical Connector adapter SC-UPC Single Mode simplex Environment and Mechanical Properties Test condition Conformance Test result Vibration 10-55Hz, 1.5mm, 60min IEC61300-2-1 ≤0.2dB Mating Durability 1000 Mating, clean every 25 mating IEC61300-2-2 ≤0.2dB Impact 1.5m, 8 drops IEC61300-2-6 ≤0.2dB Strength of Coupling Mechanism 40N, 10Min, L=22-28cm IEC61300-2-12 ≤0.2dB Temperature Cycling 40ºC to 75ºC, 40 cycles IEC61300-2-22 ≤0.2dB Temperature humidity cycling 40ºC， 95%， 96Hr IEC61300-2-21 ≤0.2dB Operating Temperature -40ºC to 85ºC Storage Temperature -40ºC to 85ºC
