TMT GLOBAL cat6 keystone jack UTP TMT-06UBP2 TMT Global Category 6 tool less U/UTP keystone Jacks give optimum protection from electromagnetic interference from an outside source. The tool-less termination allows all eight conductors to be terminated simultaneously when the termination cap is pressed into place .keystone cat6 jack UTP TMT-06UBP2 Features RJ45 8P 8C 180˚C 50u Punch Down Jack Terminating 4 pairs, 22-26 AWG Cable Universal labels color coded for T568A and T568B wiring schemes Fitting high density keystone panel UL, ETL, RoHS certified IDC contacts that allows re-termination without damaging the unit PHYSICAL AND MECHANICAL PROPERTIES Housing: High-impact Flame Retardant Polycarbonate, UL94V-0\ Contact resistance: <= 20 m Spring Wire: Phosphor Bronze With Gold-plated 3u-50u DC Resistance:0.1 ohm MAX Dielectric Withstand Volt: 100VAC RMS 60Hz Voltage: 150 VAC MAX IDC Contact: Phosphor Bronze IDC insertion life: 250 times(min.) Plug insertion Life: ≥1000 mating cycles IDC: 22-26AWG Operating Temperature Range: -60⁰ to 80⁰ Gold plating: 3 μ” IDC Accept: 22-26 AWG Plug Retention Force: 89N Wire Scheme: T568A/B Insulation Resistance: 500Ω Current Rating: 1.5A Withstanding Voltage: 1000 VAC RMS @ 60Hz / 1 min
